MaxFlo 400 – Decorative Floor System

£243.80 Excl VAT

MaxFlo 400 – Decorative floor system is an epoxy-based solvent free floor coating system designed to be used with the addition of coloured quartz aggregates.

Once cured the system gives a bright, light stable, slip-resistant finish that is hard wearing and easy to clean.

.

Clear

Description

MaxFlo 400 - Decroative Epoxy floor system

MaxFlo 400 – Decorative floor system is an epoxy-based solvent free floor coating designed to be used with the addition of coloured quartz aggregates.

Once cured the system gives a bright, light stable, slip-resistant finish that is hard wearing and easy to clean.

Once cured the product provides following characteristics:

  • Range of colours
  • Excellent adhesion
  • Chemical attack
  • Anti-slip
  • Hygienic and easily cleaned
CHEMICAL RESISTANT MORTAR

Protects

Applications

Features

Benefits

  • Concrete surfaces
  • Warehouse Flooring
  • Laboratories
  • Chemical areas
  • Washrooms and shower blocks
  • Food preparation areas
  • Solvent-free
  • 100% Solids material
  • Chemical resistance
  • Excellent wear characteristic
  • Easy mix formulation
  • Safe to use in a confined space
  • No coating shrinkage or cracking
  • Resists wide range of chemicals
  • Protects for longer
  • Aids application on site

METHOD

  • Prepare the surface
  • Mix the material
  • Apply the rein at the required thickness
  • Broadcast the aggreagate
  • Allow for curing
  • Remove excess aggregate
  • Apply resin seal coat
SURFACE PREPARATION CONCRETE

Concrete shall be a minimum of 21 days old and/or the residual moisture content shall be below 6%. Ensure that the concrete is clean and free from dust, laitance, grease, oil, curing compound and existing paint finishes etc. Blow holes and defective concrete shall be made good using a proprietary repair compound, e.g. MaxCrete 200 concrete

Suitable mechanical treatment such as vacuum grit blasting is the preferred treatment before application as this ensures a mechanical ‘key’ for the coating.

MIXING

Mixing should be with a low-speed paddle mixer. Pour the contents of the activator container into the base container and thoroughly mix until the resin goes clear, Once mixed, pour the contents of the container into a paint tray. Roller coat the material onto the primed surface using a short/ medium pile roller.  Mixing should be with a low-speed paddle mixer.

APPLICATION

Apply the material at a wet film thickness of 500 microns. While the resin system is still wet broadcast the coloured quartz aggregate onto the surface of the resin and ensure that all of the resin surface is fully blinded, you will need between 3-4kg  of coloured aggregate per m² .

Allow the aggregate to settle for 4-5 minutes and ensure that there are no ponded areas of resin showing through the surface of the aggregate. If any resin is showing on the surface, broadcast more aggregate onto these areas. Once finished ensure that the floor has a uniform layer of dry aggregate sitting on top of the resin surface.

Leave to cure for 6-8 hours at 20°C. Once the surface has dried, sweep or vacuum all of the excess quartz aggregate form the surface, before sealing.

COVERAGE



USABLE LIFE AT  20°C

45 minutes

OVER-COATING TIMES

Minimum – as soon as it is touch dry.

Maximum – over-coating time 36 hours.

Where the maximum over-coating time is passed, the material should be allowed to harden before being abraded, or flash blasted to  remove any surface contamination

ApprearanceBase
Activator
Mixed
Dark grey paste
Amber fluid
Dark grey thixotropic liquid
Mixing RatioBy Weight
By Volume
18:1
7:1
DensityBase
Activator
Mixed
2.55
0.97
2.35
Volume Capacity425cc/kg
Solids Content100%
Sag ResistanceNil at1000 microns
Usable Life10°C
20°C
30°C

50-60 minutes
30-40 minutes
15-20 minutes

Coverage1kg at a thickness of 1.0mm0.425 m²
Cure Times @ 20°CMovement without load

MAXCERAM 500 is designed for elevated temperature service in all situations requires post cure.
After an initial cure period of at least 24 hours at 20°C it should be post cured at between 60°C for 24 hours and 100°C for 2 hours.

As an alternative and where service temperature will rise gradually the material can be post cured in service after an initial cure period of at least 24 hours at 20°C
3 hours
Storage LifeUnopened and stored in dry conditions (15-30°C)5 years
Abrasion ResistanceTaber CS17 Wheels/1 Kg load85mg loss/1000 cycles
36cu mm loss/1000 cycles
AdhesionTensile Shear to ASTM D1002 on abrasive blasted mild steel with 75 micron profile220kg/cm² 3125psi
Compressive StrengthTested to ASTM D 695983kg/ cm² 13,960psi
Corrosion ResistanceTested to ASTM B1175000 hours
Flexural StrengthTested to ASTM D790614kg/cm² 8710psi)
HardnessShore D to ASTM D224020°C 89
100°C 87
150°C 86
200°C 82
240°C 78
Heat DistortionTested to ASTM D648 at 264psi fibre stress.20°C Cure 47°C
100°C Cure 126°C
150°C Cure 172°C
Heat ResistanceSuitable for long-term immersion at temperatures up to:
Resistant to dry heat in excess of:
130°C
240°C Dependant on load
Chemical ResistanceThe product resists attack by a wide variety of inorganic acids, alkalies, salts and organic media.

Additional information

Weight33 kg
Colour

, , ,

Kit Contents

25kg Coloured Quartz Aggregate, 4ltr Epoxy Sealer Resin, 4ltr Unit Epoxy Resin
