M-CORR 200 – Surface Tolerant Solvented Primer & Coating

Is a solvent based with a high solids content. Designed to provide long-term corrosion protection to the externals of new and existing steel structures even when the surface preparation is restricted.



Tag:

£122.00£477.00 Excl VAT

Clear

Description

M-CORR 200 - Surface Tolerant Solvented Primer & Coating

M-CORR 200 Surface Tolerant Solvented Primer and Coating is a solvent based material with a high solids content.

Designed to provide long term corrosion protection to the externals of new and existing steel structures even when surface preparation is restricted. The material is highly resistant to marine and industrial environments, buried conditions, effluents, salt water, most chemicals and a wide range of oils.

Typical Uses

  • External pipe protection
  • Internal pipelining
  • The lining of fuel storage tanks
  • The lining of chemical storage tanks
  • External protection for pumps, valves and process equipment

Please contact us to discuss your project before purchasing this material to confirm suitability.

Application Guide

  •
  • All oil and grease must be removed from the surface using an appropriate cleaner such as MEK or similar type solvent.
  • All surfaces must be abrasive blasted to ISO 8501/4 Standard SA2.5 (SSPC SP10/ NACE 2) minimum blast profile of 75 microns using an angular.
  • Once blast cleaned the surface must be degreased and cleaned using MEK or similar type solvent.
  • All surfaces must be coated before gingering or oxidation.
  • All surfaces must be hydro-blasted using clean water at 12,000 psi (850bar) to NACE 5 (SSPC SP13 WJ3-WJ1).
  • All surfaces must be coated before gingering or oxidation occurs
  • All oil and grease must be removed from the surface using an appropriate cleaner such as MEK.
  • All surfaces must be mechanically abraded using handheld grinders to ISO 8501/4 ST3 (SSPC SP3 ST3).
  • Once abraded, the surface must be degreased and cleaned using MEK or similar type material.
  • All surfaces must be repaired before gingering or oxidation occurs.

PLEASE NOTE: Soluble salt contaminated surfaces the substrate must be pressure washed with clean water and checked for salt contamination this process may need to be repeated several times.

Existing Concrete

  • If the concrete surface is contaminated, pressure wash using clean water.
  • Once the concrete is dry lightly abrasive blast or scarify taking care not to expose the aggregate.
  • Clean all dust and debris from the surface.

Prior to mixing please ensure the following:

  • Do not apply the material when the ambient or substrate temperature is below 10°C or when the relative humidity is higher than 90%.
  • Using a low speed electric paddle mixer, mix the 2 components until a uniform material free of any streaks is achieved.
  • Once mixing is complete use the mixed paste as soon possible.
  • Use all mixed material within 15-20 minutes at 20°C.



Brush & Roller

  • Mix and apply the material directly to the prepared surface, using a brush, roller (or airless spray).
  • stripe coat all edges, joints, corners and equipment with the mixed
    material.
  • Check the wet film thickness on a regular basis ensuring correct coating thickness of a minimum 150 microns.
  • Once the basecoat has cured sufficiently, approximately 6 hours at 20°C, apply a topcoat at a minimum wet film thickness of 150 microns.
AppearanceBase:
Activator:
Mixed:
Thin film liquid
Amber liquid
Grey solvent based liquid
Mixing RatioBy weight:
By volume:
4.5:1
4:1
Solids Content85%
Sag ResistanceNil at150 microns
Usable Life10°C
20°C
30°C

4 hours
2 hours
60 minutes


60 minutes
30 minutes
15 minutes

CoverageCan be
applied in a single coat or as a
2 coat system to properly
prepared surfaces.

The material should be applied
at a target thickness of 150
microns per coat with a theoretical
coverage rate of 6.66m² per ltr
per coat.
6.66m² per ltr per coat
Cure Times20°C
30°C
40˚C
6 hours
3 hours
90 minutes
Storage LifeUnopened and stored in dry conditions (15-30°C)5 years
Tensile ShearASTM D1002
on abrasive blasted mild steel
with 75 micron profile


ASTM 412
195kg/ cm² (2770 psi)
Corrosion ResistanceTested to ASTM B1175000 hours excellent
Salt Fog Resistance
Tested to ASTM B117
Unaffected after 10,000 hrs
Tested to ASTM B117Unaffected after 10,000 hrs
Humidity Resistance


Tested to BS3900 Part F2Unaffected after 5000 hours
Hardness


Shore D to ASTM D224080
Heat ResistanceSuitable for use in immersed
conditions at temperatures up to 40°C.

Resistant to dry heat
40°C

120°C
Brine
Crude Oil
Diesel
Hydrochloric Acid 10%
Naphtha
Phosphoric Acid 25%
Sodium Hydroxide 35%
Sulphuric acid 20%
40˚C
40˚C
40˚C
40˚C
40˚C
40˚C
40˚C
40˚C

Additional information

Unit Size

20ltr, 4ltr

Colour

Light grey

Mixing Ratio

3:1 By Volume, 3.25:1 By Weight
