M-METAL 800 – Metal Fairing Compound – Standard Cure

£79.50£201.25 Excl VAT

Clear
Loading...

Description

M-METAL 800 - Metal Fairing Compound - Standard Cure

Is a high performance two pack solvent free Epoxy Fairing Compound and filler. The material is ideal for use on metallic surfaces and has been designed to be applied to manually prepared substrates.

M-METAL 800 can be applied by trowel or stiff brush to large areas where excessive corrosion pitting is prevalent.

Once cured the product can be over coated with standard epoxy, acrylic and polyurethane coatings and paint systems.

Typical Uses

  • Filling Pitting on Corroded Tanks &  Structural Steel
  • As a Fairing Compound for Pipe Repairs

Application Guide

  • All oil and grease must be removed from the surface using an appropriate cleaner such MEK or similar type solvent.
  • All surfaces must be abrasive blasted to ISO 8501/4 Standard SA2.5 (SSPC SP10/ NACE 2) minimum blast profile of 75 microns using an angular.
  • Once blast cleaned, the surface must be degreased and cleaned using MEK or similar type solvent.
  • All surfaces must be coated before gingering or oxidation.
  • All oil and grease must be removed from the surface using an appropriate cleaner such as MEK.
  • All surfaces must be mechanically abraded using handheld grinders to ISO 8501/4 ST3 (SSPC SP3 ST3).
  • Once abraded, the surface must be degreased and cleaned using MEK or similar type material.
  • All surfaces must be repaired before gingering or oxidation occurs.

Prior to mixing please ensure the following:

  • Warm the base component is at a temperature between 15-25°C.
  • Ensure the ambient & surface temperature is above 5°C or less than 3°C above dew point.
  • Mix both Part-A and part-B together in full units as supplied. For small quantities us a mixing ratio of: 1:1 by volume or 1:1 by weight
  • When mixing both materials together, it is very important to have a uniform grey paste that is streak free.

Once mixing is complete, use all mixed material within 20-25 minutes at 20°C.

  • Apply the mixed material directly to the prepared surface as soon as possible after mixing. Using a short-bristled brush, spatula, squeegee or plastic applicator.

  • Minimum – the applied material can be over-coated as soon as it is touch dry.
  • Maximum – the over-coating time should not exceed 6 hours.

Where the maximum over-coating time is exceeded, the material should be allowed to harden before being abraded or flash blasted to remove surface contamination.

AppearanceBase
Activator
Mixed
Black paste
Brown paste
Dark Brown paste
Mixing RatioBy Weight
By Volume
1:1
1:1
DensityBase
Activator
Mixed
1.6
1.6
1.6
Volume Capacity625cc/kg
Solids Content100%
Slump ResistanceNil at2.0 cm
Usable Life20°C
30°C

25 minutes
12.5 minutes

Coverage1kg at a thickness of 1.0mm0.625 m2
Cure Times @ 20°CMovement without load or immersion:
Machining and light loading:
Full loading:
Immersion:
2 hours
6 hours
2 days
3 days
Storage LifeUnopened and stored in dry conditions (15-30°C)5 years
AdhesionTensile Shear to ASTM D1002 on abrasive blasted mild steel with 75 micron profile

Manual Prep
865kg/cm² 12,300psi


129kg/cm² 1830psi
Compressive StrengthTested to ASTM D 695735kg/ cm² 10,450psi
Flexural StrengthTested to ASTM D790298kg/cm² 4520psi
HardnessRockwell R to ASTM d785100
Heat ResistanceSuitable for long term water immersion at temperatures up to:
Resistant to dry heat in excess:
70°C
150°C
Chemical ResistanceThe product resists attack by a wide variety of inorganic acids, alkalis, salts and organic media.

M-METAL 800 – BASE – MSDS

M-METAL 800 – ACTIVATOR – MSDS

Additional information

Weight 16 kg
Unit Size

1kg, 3kg

Colour

Dark Grey

Mixing Ratio

1.65:1 By Weight, 4:1 By Volume

Kit Contents

1 x Plastic Applicator Tool, 1 x Plastic Spatula

Number of Coats

1 – 20mm max

Pot Life @ 20°C

40 Mins

Coverage per Unit

0.625 sqm at 1.0mm
