M-CRETE 300 – Acid Resistant Epoxy Novolac Concrete Screed

M-CRETE 300 - Acid Resistant Epoxy Novolac Concrete Screed

£544.82 Excl VAT

M-CRETE 300 – Acid Resistant Epoxy Novolac Concrete Screed

£544.82 Excl VAT

Is formulated with Epoxy novolac resins, when cured the material provides excellent chemical resistance to strong acids and industrial chemicals. Designed principally for the long-term protection of concrete surfaces subject to chemicals, either in immersed conditions or incidental contact.

Description

M-CRETE 300 – Acid Resistant Epoxy Novolac Concrete Screed

M-CHEM 300 – Acid Resistant Epoxy Screed is formulated using a highly acid resistant Epoxy Novolac Resin System.

M-CHEM 300 – Acid Resistant Epoxy Screed is solvent free and has been designed for various concrete repair applications and to protect concrete surfaces in high traffic areas where concentrated acids and industrial chemicals are present.

The product can be applied to new or old concrete and should be applied at a minimum thickness of 5mm with a maximum of up to 20mm.

Typical Uses

Application Guide

Existing Concrete

  • If the concrete surface is contaminated, pressure wash using clean water.
  • Once the concrete is dry, lightly abrasive blast or scarify taking care not to expose the aggregate.
  • Clean all dust and debris from the surface and take several moisture readings and prime with M-PRIME 100 – Low Viscosity Epoxy Concrete Primer or M-PRIME 104 – Damp Tolerant Concrete Primer dependant on moisture readings obtained.
  • Apply M-PRIME 100 or M-PRIME 104 at a target wet film of 150 microns, allow to cure before overcoating.
  • For very porous surfaces a second coat of primer may be required.

New Concrete

  • Allow new concrete to cure for a minimum of 21 days lightly abrasive blast or scarify to remove any surface laitance.
  • Clean all dust and debris from the surface and take several moisture readings and prime with M-PRIME 100 – Low Viscosity Epoxy Concrete Primer or M-PRIME 104 – Damp Tolerant Concrete Primer dependant on moisture readings obtained.
  • Apply M-PRIME 100 or M-PRIME 104 at a target wet film of 150 microns, allow to cure before overcoating.

For very porous surfaces a second coat of primer may be required.

Prior to mixing please ensure the following:

  • The base component is at a temperature between 15-25°C.
  • Do not apply the material when the ambient or substrate temperature is below 10°C or less than 3°C above dew point.

Contents

1 x 30kg Unit of M-CRETE 300 consists of:

  • 1 x 4ltr of M-CRETE 300 Screed Resin (grey or red) and Activator (amber).
  • 1 x 20ltr pail containing 24kg of aggregate.

Mixing

  • Empty the contents of the M-CRETE 300 – Activator into the M-CRETE 300 – Base tin and mix using a low speed electric paddle mixer.
  • Ensure all the material is thoroughly mixed and streak free, pay attention to the sides and bottom of the tin. Once mixed, pour the resin into a forced action mixer.
  • Add approximately half of the supplied aggregate to the resins in the forced action mixer and mix for 2/3mins.
  • Once the resins and aggregate are fully wetted, gradually add the remainder of the aggregate to the resins.

Warning

  • When the product is being applied to concrete surfaces lower than 12°C, add 50% of the aggregate and check the consistency of the mix. Colder temperatures will thicken the resin and therefore less aggregate is required to create a trowelable screed.
  • Once the resins and aggregate are full wetted, gradually add the remainder of the aggregate until the required consistency is achieved. Do not worry if you have some aggregate left.

Use all mixed material within 25 minutes at 20°C.

  • To apply M-CRETE 300 chemical Resistant Epoxy Screed Empty the contents from mixer onto the repair area.
  • Spread the screed with a trowel or rubber squeegee and then smooth off to the correct level.
  • Once the repair area has been filled with material spray clean water onto the face of the trowel and skim the surface of the repair.
AppearanceBase
Activator
Aggregate
Grey thixotropic liquid
Amber liquid
Grey milled powder
Mixing RatioBy Weight
4.7:1
DensityBase
Activator
Aggregate
Mixed
1.41
1.02
2.7
2.16
Solids Content100%
Sag ResistanceNil at20mm
Usable Life10°C
20°C
30°C

50 minutes
25 minutes
12 minutes

Coverage 30kg/ 13.9ltrs of mixed product will give the following coverage rates

2.78m² at 5mm
1.39m² at 10mm
0.695m² at 20mm
Cure Times at 20°C Minimum overcoating time
Foot Traffic
Vehicles
Chemical immersion
6 hours
24 hours
48 hours
5 days
Storage LifeUnopened and stored in dry conditions (15-30°C)5 years
Abrasion ResistanceTaber CS17 Wheels/1 Kg load145mg loss/1000 cycles
0.53cc loss/1000 cycles
Direct Pull off AdhesionTested to ASTM D406035kg/cm² (500psi)
Concrete failure
Impact ResistanceTested to ASTM G141.8 joules
Compressive StrengthTested to ASTM D 695880kg/cm² (12500psi)
Flexural StrengthTested to ASTM D790490kg/cm² (7000psi)
ShrinkageTested to ASTM C246
Nil
Chemicals & ConcentrationsTest Temperature
Acetic Acid 10%
Ammonia Hydroxide 30%
Benzene 100%
Butanol 100%
Chromic Acid 10%
De-ionised Water
Ethanol 100%
Hydrobromic Acid 40%
Hydrochloric Acid 36%
Nitric Acid 10%
Phosphoric Acid 75%
Steam out
Sulphuric Acid 98%
Toluene 100%
Xylene 100%

30˚C
45˚C
35˚C
40˚C
40˚C
40˚C
45˚C
30˚C
35˚C
30˚C
45˚C
180˚C
40˚C
40˚C
40˚C



Additional information

Weight 32 kg
Colour

Grey, Red

Unit Size

30kg

Coverage per Unit

2.5 sqm at 4.0mm

Material

Epoxy Novolac
